TracoPower TES 1-0511V DC/DC converter (SMD) 5 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 10.92
30
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 10.92 / piece)
€
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TES 1-0511V
- Nominal voltage
5 V DC
- Min. input voltage
4.5 V DC
- Input voltage (max.)
5.5 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
75 %
1 W
- Insulation voltage
3000 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 16.3 x 8 x 8 mm
- Height
8 mm
- Length
16.3 mm
- Width
8 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
2 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370715 TracoPower TES 1-0511V DC/DC converter (SMD) 5 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370715 TracoPower TES 1-0511V DC/DC converter (SMD) 5 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370715 TracoPower TES 1-0511V DC/DC converter (SMD) 5 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370715 TracoPower TES 1-0511V DC/DC converter (SMD) 5 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact SMD casing with industry-standard pinning, E/A-insulation 3000 V/DC, high accuracy of Pin-Co-planar intensity. Suitable for lead-free soldering process after IPC/JEDEC J-STD-020C.
