TracoPower TES 1-1210V DC/DC converter (SMD) 12 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.92
3
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.92 / piece)
€ 10.92
plus VAT.
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TES 1-1210V
- Nominal voltage
12 V DC
- Min. input voltage
10.8 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
260 mA
- Output current (max.) - rounded
260 mA
- Efficiency (max.)
73 %
1 W
- Insulation voltage
3000 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 16.3 x 8 x 8 mm
- Height
8 mm
- Length
16.3 mm
- Width
8 mm
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
2 g
- Content
1 pc(s)
- Type
TES 1-1210 V
Documents & Downloads
Datasheet
Datasheet 1510178 TracoPower TES 1-1210V DC/DC converter (SMD) 12 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510178 TracoPower TES 1-1210V DC/DC converter (SMD) 12 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510178 TracoPower TES 1-1210V DC/DC converter (SMD) 12 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact SMD casing with industry-standard pinning, E/A-insulation 3000 V/DC, high accuracy of Pin-Co-planar intensity. Suitable for lead-free soldering process after IPC/JEDEC J-STD-020C.
This text is machine translated.
