TracoPower TMG 15124 AC/DC PSU (print) 24 V DC 0.62 A 15 W
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 35.29 / piece)
€
Highlights & Details
AC/DC PCB power supply TracoPower TMG 15124 24 V/DC 625 mA 15 W
- Output 24 V DC / 0.62 A
- Power 15 W
- Solder pins
Technical specifications
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
0.62 A
- Output current (max.) - rounded
620 mA
- Min. input voltage
90 V AC
- Dim
(L x W x H) 19.1 x 27.2 x 41.2 mm
- Output voltage (max.)
24 V DC
- Connection
Solder pins
15 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Min. operating temperature (derating)
-40 °C
- Weight
47 g
- Width
27.2 mm
- Height
41.2 mm
- Length
19.1 mm
- Type
TMG 15124
Documents & Downloads
Datasheet
Datasheet 3371553 TracoPower TMG 15124 AC/DC PSU (print) 24 V DC 0.62 A 15 W
User & Safety Instructions
User & Safety Instructions 3371553 TracoPower TMG 15124 AC/DC PSU (print) 24 V DC 0.62 A 15 W
Warranty Terms
Warranty Terms 3371553 TracoPower TMG 15124 AC/DC PSU (print) 24 V DC 0.62 A 15 W
Description
Compact, fully cast power supplies with high packing density
PCB mounting using soldering pins
Input filter in accordance with EN 55022, class B
Safety standards according to IEC/EN/UL 60950-1
Short circuit and surge protection
This text is machine translated.
PCB mounting using soldering pins
Input filter in accordance with EN 55022, class B
Safety standards according to IEC/EN/UL 60950-1
Short circuit and surge protection
