Buy TracoPower TML 20212C AC/DC PSU (print) 12 V DC 0.833 A 20 W

'TRACO POWER TML 20115' power supply module, input 100-240 VAC, output 15 VDC, 1,600 mA. Rectangular, black housing with pins.

Datasheet (PDF)

Sales and shipping:

Number

Piece(s)

Minimum order quantity: 10

Total (€ 70.58 / piece)

€

Report legal concerns

Highlights & Details

AC / DC power supply module TML series, 5 - 30 watts

Output 12 V DC/0.833 A;Power 20 W;Input voltage 85 - 264 V AC

Technical specifications

max. 120 - 180 % (foldback)

Product type: AC/DC PSU (print)

Input voltage (max.): 264 V AC

Max. output current: 0.833 A

Output current (max.) - rounded: 833 mA

Min. input voltage: 85 V AC

Dim: (W x H) 55 mm x 28 mm

Output voltage (max.): 12 V DC

: 20 W

No. of outputs: 2 x

Output voltage 1: +12 V

Output voltage 2: -12 V

Output current 1: 833 mA

Output current 2: 833 mA

Operating temperature: -25 to +60 °C

Insulation voltage: 3000 V AC

Width: 55 mm

Height: 28 mm

Residual ripple: Max 1.5 %

Type: TML 20212C

Input voltage: 85 - 264 V AC

Mains control: max. ±0.3 %

Documents & Downloads

Datasheet

Datasheet 3370026 TracoPower TML 20212C AC/DC PSU (print) 12 V DC 0.833 A 20 W

User & Safety Instructions

User & Safety Instructions 3370026 TracoPower TML 20212C AC/DC PSU (print) 12 V DC 0.833 A 20 W

Warranty Terms

Warranty Terms 3370026 TracoPower TML 20212C AC/DC PSU (print) 12 V DC 0.833 A 20 W

Description

AC/DC-power supply module in cast plastic casing. Wide-range input for worldwide usage. High degree of efficiency, low noise and low remaining ripple. Short-circuit and overload protection. Radio interference suppression acc. EN 55022, class B and FCC, Level B UL 94V-0. Security in accordance with UL 1950, IEC / EN 60950 3 years warranty.
