TracoPower TPP 15-105A-D SMPSU 5 V DC 3000 mA 15 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 43.99 / piece)
€ 43.99
incl. VAT
14-day return policy included
Highlights & Details
AC/DC-Switching power supply, TPP 15-Series
- 15 Watt power supply unit for medical applications in open frame housing (soldering pins)
- Safety standards according to IEC/EN/ES 60601-1, 3rd Edition, 2x MOPP
- Risk management according to ISO 14971
- Protected against permanent short circuit
- I/O INSULATION 4000 VAC
- Protection classes I and II.
- This text is machine translated.
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
3000 mA
- Output current (max.) - rounded
3 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 38.1 x 25.4 x 25.8 mm
- Output voltage (max.)
5 V DC
- Connection
Solder pins
15 W
- No. of outputs
1 x
- Type
open
- Weight
16.5 g
- Width
25.4 mm
- Height
25.8 mm
- Length
38.1 mm
- Type
TPP 15-105A-D
- Output current (min.)
0 mA
- Output voltage (min.)
5 V DC
- Max. temperature
85 °C
- Min. temperature
-40 °C
