Tremba HMF-1614d.002-12VDC,100% Solenoid repelling 0.1 N 2.5 N 12 V DC 2 W

1/2
Product type
Solenoid
Type
repelling
Connection
Open end cable
Nominal voltage
12 V DC
Nominal lift
4 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct

22 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions

Number
Total (€ 11.99 / piece)
€ 14.99
-20 %
€ 11.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included

Technical specifications

Product type

Solenoid

Type

HMF-1614d.002-12VDC,100%

Type

repelling

Connection

Open end cable

Cable length

21.00 cm

Nominal voltage

12 V DC

Nominal lift

4 mm

2 W

Initial force

0.1 N

Peak force

2.5 N

Weight

32 g

Thread size

M3

Length

30 mm

Width

16 mm

Height

14 mm

Dim

(L x W x H) 30 x 16 x 14 mm

Type

pressing

Nominal voltage (details)

12 V DC

Type

HMF-1614d.002-12VDC, 100%

Fitting method

M3

Nominal power

2 W

Documents & Downloads

Datasheet

Datasheet 503743 Tremba HMF-1614d.002-12VDC,100% Solenoid repelling 0.1 N 2.5 N 12 V DC 2 W

User & Safety Instructions

User & Safety Instructions 503743 Tremba HMF-1614d.002-12VDC,100% Solenoid repelling 0.1 N 2.5 N 12 V DC 2 W

Description

Lift magnet in clamp design Industrial designs according to European standards. Connection type: wire (approximately 21 cm). Insulating material class B (130 °C). Power specifications are applicable for coil at operating state temperature, power values for cold coil approximately + 25% (depending on model). Oppressive designs including retaining spring. Length of stroke and power can be arranged via electronic control. Ideal for price sensitive industrial applications due to multipurpose modification options.
