Name: TRU COMPONENTS SIL socket (precision) No. of rows: 1 Pins per row: 36 TC-0306-036-1-50-10 1 pc(s)
Brand: TRU COMPONENTS
SKU: 1560794
Availability: InStock

A series of soldered pin headers with 27 pins, positioned at an angle, suitable for electronic connections.

Image similar

Connector type

Power strip, straight

Product type

SIL socket (precision)

No. of rows

Total number of pins

2.54 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Wed 4 Nov

474 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 4.29 / piece)

€ 4.29

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Content 1 pc(s)
No. of rows 1
Pins per row 36

Our service for you

Technical specifications

Connector type: Power strip, straight

Product type: SIL socket (precision)

No. of rows: 1

Pins per row: 36

Total number of pins: 36

CS: 2.54 mm

Connection: Print

Factory colour: Black

Pin shape: Rectangular

Nominal voltage: 150 V AC

Nominal current: 3 A

Nominal current - rounded value: 3 A

Contact surface: Tin plated

Contact material: Copper alloy

Case material: Thermoplastic material

Pin Ø: 0.60 mm

Pin length (PCB): 3 mm

Separable: Yes

Dim: (L x W x H) 10.00 x 10.00 x 2.54 mm

Connector orientation: Perpendicular (to the PCB)

Manufacturer part #: TC-0306-036-1-50-10

Socket depth: 5.80 mm

Industrial packaging: No

Content: 1 pc(s)

Width: 10.00 mm

Height: 2.54 mm

Length: 10.00 mm

RoHS-compliant: Yes

Max. temperature: +125 °C

Min. temperature: -55 °C

Type: TC-0306036-1-50-10
