VOKA Kabelwerk LiYY Control lead 6 x 0.25 mm² Grey (RAL 7001) LIYY6X025 100 m
EAN:
Part number:
Item no:
Product type
Control lead
No. of leads
6 x
Cross section (each core)
0.25 mm²
Cable type
LiYY
Outside Ø
5.10 mm
Datasheet (PDF)
Number
Total (1 m = € 0.79)
€ 78.98
plus VAT.
Technical specifications
- Product type
Control lead
- No. of leads
6 x
- Content
100 m
- Cross section (each core)
0.25 mm²
- Cable type
LiYY
- Outside Ø
5.10 mm
- Packaged
Yes
- Wire ID code
According to DIN 47100
- Bend radius (no. of ODs for fixed installation)
10
- Bend radius (no. of ODs for flexible installation)
10
- Halogen-free
No
- Manufacturer part #
LIYY6X025
- Factory colour
Grey (RAL 7001)
- Insulation material
PVC
- Core layout
14 x 0.15 mm
- Material (details)
Copper wire, blank
- Sold per metre
No
- Nominal voltage
500 V
- Test voltage
1500 V
- Cross section
6 x 0.25 mm²
- Max. temperature range (flexible installation)
50 °C
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (fixed installation)
80 °C
- Min. temperature range (fixed installation)
-30 °C
- Type
LiYY 6x0,25qmm PVC
- Standards
In accordance with DIN VDE 0812
Documents & Downloads
Datasheet
Datasheet 1343481 VOKA Kabelwerk LiYY Control lead 6 x 0.25 mm² Grey (RAL 7001) LIYY6X025 100 m
