WAGO 750-1501 PLC digital output module 750-1501 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 189.99 / piece)
€ 189.99
incl. VAT
14-day return policy included
Technical specifications
- 16DO 24V DC 0.5A Ribbon Cable/ LSS
- Product type
PLC digital output module
- Type
750-1501
- No. of outputs (max.)
16
- Operating voltage
24 V DC
- Height
73 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
IP20
- Dim
(L x W x H) 100 x 12 x 73 mm
- Manufacturer part #
750-1501
- Weight
43.4 g
- Connection
Ribbon
- Factory colour
Light grey
- Mounting type
DIN rail
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 190511 WAGO 750-1501 PLC digital output module 750-1501 1 pc(s)
User & Safety Instructions
User & Safety Instructions 190511 WAGO 750-1501 PLC digital output module 750-1501 1 pc(s)
Description
24 V DC, 00,208333333333333, ribbon cable, negative switch, light gray.
This text is machine translated.
This text is machine translated.
