WAGO 750-427 PLC digital input module 750-427 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 61.99 / piece)
€ 61.99
incl. VAT
14-day return policy included
Technical specifications
- 2DI 110V DC NPN/PNP INPUT +
- Product type
PLC digital input module
- Type
750-427
- No. of digital inputs (max.)
2
- Operating voltage
110 V DC
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
IP20
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
750-427
- Weight
47.214 g
- Factory colour
Light grey
- Mounting type
DIN rail
- Inputs / outputs
Inputs: 2
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 191700 WAGO 750-427 PLC digital input module 750-427 1 pc(s)
User & Safety Instructions
User & Safety Instructions 191700 WAGO 750-427 PLC digital input module 750-427 1 pc(s)
Description
DC 110 V, configurable positive switch or negative switch, light gray.
This text is machine translated.
This text is machine translated.
