WAGO 750-460/000-005 PLC analogue input module 750-460/000-005 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 419.00 / piece)
€ 419.00
incl. VAT
14-day return policy included
Technical specifications
- Color: light gray
- Cross-section 0.08 - 2.5 mm²
- AWG 28 - 14
- Stripping length: 8 - 9 mm
- Installation type: TS 35
- Protection class: IP20
- Operating temperature: 0 to + 55 °C
- Product type
PLC analogue input module
- Type
750-460/000-005
- No. of analogue inputs
4
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
IP20
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
750-460/000-005
- Weight
55.003 g
- Factory colour
Light grey
- Mounting type
DIN rail
- Inputs / outputs
Inputs: 4
- Operating voltage
Via the system voltage/DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 191744 WAGO 750-460/000-005 PLC analogue input module 750-460/000-005 1 pc(s)
User & Safety Instructions
User & Safety Instructions 191744 WAGO 750-460/000-005 PLC analogue input module 750-460/000-005 1 pc(s)
Description
Ni1000/RTD, for resistance sensors, light gray.
This text is machine translated.
This text is machine translated.
