WAGO 750-609 PLC supply module 750-609 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 59.99 / piece)
€ 59.99
incl. VAT
14-day return policy included
Technical specifications
- SUPPLY T.BL. FUSE 230 V AC
- Product type
PLC supply module
- Interfaces
Terminals
- Type
750-609
- Operating voltage
230 V AC
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
750-609
- Weight
50.841 g
- Mounting type
DIN rail
12
100 mm
69.8 mm
FALSE
AC
FALSE
0
0
0
0
0
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
Spring clamp connection
TRUE
ATEX gas-ex-protection, Cat. 3G
ATEX dust-ex-protection, Cat. 3D
FALSE
FALSE
IP20
FALSE
FALSE
0
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
230-230 V
230-230 V
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 191979 WAGO 750-609 PLC supply module 750-609 1 pc(s)
User & Safety Instructions
User & Safety Instructions 191979 WAGO 750-609 PLC supply module 750-609 1 pc(s)
Description
With fuse holder, AC 230V, light gray.
This text is machine translated.
This text is machine translated.
