WAGO 753-653 PLC serial interface 753-653 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 465.00 / piece)
€ 465.00
incl. VAT
14-day return policy included
Technical specifications
- RS 485 Interface
- Product type
PLC serial interface
- Interfaces
RS 485
- Type
753-653
- No. of digital inputs (max.)
1
- No. of outputs (max.)
1
- Height
64 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
IP20
- Dim
(W x H x D) 12 x 64 x 100 mm
- Manufacturer part #
753-653
- Weight
48.5 g
- Connection
Spring-loaded terminal
- Mounting type
DIN rail
- Depth
100 mm
- Operating voltage
Via the system voltage DC/DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 192234 WAGO 753-653 PLC serial interface 753-653 1 pc(s)
User & Safety Instructions
User & Safety Instructions 192234 WAGO 753-653 PLC serial interface 753-653 1 pc(s)
Description
RS-485/9600/N/8/1, light gray.
This text is machine translated.
This text is machine translated.
Hints
Accessories plug 753-110 is not included. Please order separately.
