Alutruss BILOCK BQ2-2500 Ladder truss 2.5 m
EAN:
Part number:
Item no:
Datasheet (PDF)
16 Piece(s)
Sales and shipping:
Number
Total (€ 147.05 / piece)
€
Highlights & Details
BILOCK BQ2-2500 2-point traverse
- 2-point traverse system
Technical specifications
- Longitudinal pipes 50 x 2 mm
- Braces 16 x 2 mm
- Pipe material AlMgSi 0.5
- Welding material ALMg 5
- Welding method TIG pulse.
- Dimensions 240 mm (center of hole - center of hole)
- Length: 2500 mm
- Product type
Ladder truss
- Tube diameter
50 mm
- Length
2.5 m
- Width
29 cm
- Height
5 cm
- Weight
6 kg
- Dim
(L x W x H) 2.5 m x 29 cm x 5 cm
Documents & Downloads
Datasheet
Datasheet 593829 Alutruss BILOCK BQ2-2500 Ladder truss 2.5 m
User & Safety Instructions
User & Safety Instructions 593829 Alutruss BILOCK BQ2-2500 Ladder truss 2.5 m
Description
2-point traverse system · High-quality aluminum pipes with 50 mm diameter · Easy to set up · Lowest weight · For assembly at exhibitions and in shops and disco and theatre installations.
This text is machine translated.
This text is machine translated.
