Analog Devices AD592AN AD592AN Transducer module -25 up to +105 °C TO-92 Radial lead
EAN:
Part number:
Item no:
Temperature reading range (max.)
+105 °C
Connector
Solder pins
Type
Radial lead
Product type
Transducer module
Type
AD592AN
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 20.16
3
5% = € 1.00
€ 19.16
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 20.16 / piece)
€ 20.16
plus VAT.
Highlights & Details
Analog Devices AD592AN AD592AN Transducer module -25 up to +105 °C TO-92 Radial lead
- Linear-IC
Technical specifications
- Linearity ± 0.15 K
- Output current (25 °C): 296.7 - 299.7 µA
- Type
AD592AN
- Temperature reading range (min.)
-25 °C
- Temperature reading range (max.)
+105 °C
- Temperature reading range
-25 up to +105 °C
- Connector
Solder pins
- Orientation (connectors)
Radial
- Type
Radial lead
- Enclosure
TO-92
- Min. operating voltage
4 V DC
- Max. operating voltage
30 V DC
- Operating voltage
4 - 30 V DC
- Accuracy
0.5 °C
- Type
Temperature measurement converter
- Connection
Soldering pins
- Temperature range
-25 - +105 °C
- Reading range
-25 - +105 °C
- Operating voltage
4 - 30 V
- Product type
Transducer module
Documents & Downloads
Datasheet
Datasheet 174912 Analog Devices AD592AN AD592AN Transducer module -25 up to +105 °C TO-92 Radial lead
User & Safety Instructions
User & Safety Instructions 174912 Analog Devices AD592AN AD592AN Transducer module -25 up to +105 °C TO-92 Radial lead
Description
This monolithic module is a high-precision, temperature-independent power source. The output current in µA corresponds exactly to the temperature in Kelvin. So at 25 ºC there is a current of 298.2 µA, corresponding to 298.2 K (0 K = - 273,2 ºC). The sensor possesses an excellent linearity of only 0.15 K. Without additional calibration, the tolerance amounts to ± 1.5 K. This mistake can be compensated very simply by a resistant trimmer so that only the linearity mistake appears. Linearity ± 0.15 K
