APEM 637NH/2 637NH/2 Toggle switch 250 V AC 10 A 1 x (On)/Off/(On) momentary/0/momentary 1 pc(s)
EAN:
Part number:
Item no:
Switch/button features
Plastic lever
Casing/button colour
Black
Functions
momentary/0/momentary
Lighting type
None
Switch position
1 x (On)/Off/(On)
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 7.19
5
6% = € 0.43
€ 6.76
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 7.19 / piece)
€
Highlights & Details
APEM 637NH/2 637NH/2 Toggle switch 250 V AC 10 A 1 x (On)/Off/(On) momentary/0/momentary 1 pc(s)
- ()
Technical specifications
- Current Pitze Peak current max. 30 A during 1/2 sine wave, 250 V/AC
- Switch/button features
Plastic lever
- Casing/button colour
Black
- Type
Insulated lever
- Functions
momentary/0/momentary
- Lighting type
None
- Switch position
1 x (On)/Off/(On)
- Connection
Type C CEE 7/16 plug 6.3 mm
Solder tag
- Number of pins
1
- Contact resistance
(At 1 A / 2 V / DC) 10 mΩ
- Switching voltage
250 V AC
- Switching current (max.)
10 A
- Dielectric strength
(Between terminals) 2000 Veff/50 Hz, (between terminals and ground) 2500 Veff/50 Hz
- Recess diameter
12 mm
- Electrical lifespan
10000 cycles
- Front panel thickness
4.5 mm
- Insulation resistance
1000 MΩ/500 V
- Dim
- RoHS-compliant
- Type
637NH/2
- Switching current
10 A
- Type
637NH/2
- Pins
1
- Connection
Solder lugs/plug connection (6.35 x 0.8 mm)
- Product type
Toggle switch
Documents & Downloads
Datasheet
Datasheet 700753 APEM 637NH/2 637NH/2 Toggle switch 250 V AC 10 A 1 x (On)/Off/(On) momentary/0/momentary 1 pc(s)
User & Safety Instructions
User & Safety Instructions 700753 APEM 637NH/2 637NH/2 Toggle switch 250 V AC 10 A 1 x (On)/Off/(On) momentary/0/momentary 1 pc(s)
Description
Hints
Re switch position: content in parentheses describes the n/o and n/c contact constellation
