Banana PI OpenWrt One 1 GB 2 x
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 117.64 / piece)
€ 117.64
plus VAT.
Highlights & Details
OpenWrt One, Dual band Wifi6 (2.5&5 GHz), 2.5 GbE WAN & GB LAN, PoE, RTC
- OpenWRT support
- Dual band Wi-Fi 6 (2.4 GHz & 5 GHz)
- 2.5 GbE WAN and Gigabit LAN port
- 1 GB DDR4 RAM & 256 MB SPI NAND
- M.2 NVMe SSD expansion socket
- PoE support and RTC with battery backup
Technical specifications
- MediaTek MT7981B (filogic 820) Dual-core Cortex A53 @ 1.3 GHz
- Dual band Wi-Fi 6 via MediaTek MT7976C (2x2 2.4 GHz + 3x3 5 GHz)
- 1x 2.5 GbE RJ45 & 1x Gigabit Ethernet RJ45
- 256 MB SPI NAND AND 16 MB SPI NOR FLASH
- M.2 2242/2230 socket for NVMe SSD (PCIe Gen 2x1)
- RTC support, PoE support, microbus socket
- 3x connection for MMCX antenna
- 1x USB 2.0 type A, 1x USB type C
- 15 V USB-PD VIA USB-C.
- Product type
Routerboard computer
- Processor
ARM Cortex-A53
- Processor cores (No.)
2 x
1 GB
- Memory type
DDR4
- Memory capacity
256 MB
- Internal ports
M.2
- External ports
2x LAN (10/100/1000)
1x USB 2.0
USB-C® (current)
- Wi-Fi
built-in
- Power supply (LOV)
via USB
- Width
915 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3403895 Banana PI OpenWrt One 1 GB 2 x
User & Safety Instructions
User & Safety Instructions 3403895 Banana PI OpenWrt One 1 GB 2 x
Description
The Banana PI OpenWrt One router is the perfect solution for anyone looking for a powerful, versatile router. With official support from the OpenWrt community, this router not only offers the proven open source software, but also the latest technology for maximum performance.
Equipped with the MediaTek MT7981B SoC and WiFi 6, this router enables lightning-fast connections in both the 2.4 GHz and 5 GHz bands
Stable, uninterrupted network use. The OpenWrt One is particularly failsafe thanks to the robust design with 1 GB DDR4 RAM and 256 MB SPI NAND memory. A dedicated Dual storage system protects against the "brick" state and guarantees reliable recovery.
The router also features an M.2 SSD socket for additional memory expansion, Ideal for demanding applications such as NAS or IoT projects. A 2.5GBE
A WAN port and a gigabit LAN port offer fast data transfer for all connected devices.
The support for Power over Ethernet (PoE) as well as an RTC with battery backup open additional flexibility and enable the operation in different network configurations. Expansion modules can be added via the microbus base, WAS further increases the adaptability of the router.
With its open architecture and the numerous functions the Banana PI OpenWrt One router is aimed at developers, makers and advanced users looking for a stable, powerful network device. Ideal for DIY projects, OpenWrt development and demanding network applications.
Rely on the Banana PI OpenWrt One router - the basis for your next technical masterpiece.
This text is machine translated.
Equipped with the MediaTek MT7981B SoC and WiFi 6, this router enables lightning-fast connections in both the 2.4 GHz and 5 GHz bands
Stable, uninterrupted network use. The OpenWrt One is particularly failsafe thanks to the robust design with 1 GB DDR4 RAM and 256 MB SPI NAND memory. A dedicated Dual storage system protects against the "brick" state and guarantees reliable recovery.
The router also features an M.2 SSD socket for additional memory expansion, Ideal for demanding applications such as NAS or IoT projects. A 2.5GBE
A WAN port and a gigabit LAN port offer fast data transfer for all connected devices.
The support for Power over Ethernet (PoE) as well as an RTC with battery backup open additional flexibility and enable the operation in different network configurations. Expansion modules can be added via the microbus base, WAS further increases the adaptability of the router.
With its open architecture and the numerous functions the Banana PI OpenWrt One router is aimed at developers, makers and advanced users looking for a stable, powerful network device. Ideal for DIY projects, OpenWrt development and demanding network applications.
Rely on the Banana PI OpenWrt One router - the basis for your next technical masterpiece.
This text is machine translated.
