BLOCK VCM 16/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 16 VA 2.6 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 14.28
3
6% = € 0.79
€ 13.49
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 14.28 / piece)
€ 14.28
plus VAT.
14-day return policy included
Highlights & Details
BLOCK VCM 16/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 16 VA 2.6 A
- to N/A
- Excellent size to power ratio
- Vacuum resin moulded (self extinguishing to UL 94 V-0)
- Mounting tabs on side of housing
Technical specifications
- Product type
PCB mount transformer
- Output voltage
6 V AC
- Output voltage (number x voltage)
1 x 6 V AC
- Output current
2.6 A
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
16 VA
- Type
VCM 16/1/6
- Connection
Soldering
- Frequency
50 - 60 Hz
- Weight
0.42 kg
- Content
1 pc(s)
- Insulation class
VDE=B, UL=105
- Test voltage
500 V
- Test mark
C-UL-US, ENEC 10 (VDE)
- RoHS-compliant
Yes
- Max. ambient temperature
+40 °C
- Efficiency
76 %
16 VA
- Output voltage
6 V
Documents & Downloads
Datasheet
Datasheet 710693 BLOCK VCM 16/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 16 VA 2.6 A
User & Safety Instructions
User & Safety Instructions 710693 BLOCK VCM 16/1/6 PCB mount transformer 1 x 230 V 1 x 6 V AC 16 VA 2.6 A
Description
VCM Simple tension
Hints
For more technical data on BLOCK's VCM 16/1/6 PCB transformer, please see its datasheet under 'downloadable documents'.
