Image similar
Image similar
BLOCK VCM 16/1/12 PCB mount transformer 1 x 230 V 1 x 12 V AC 16 VA 1.33 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 14.28
3
6% = € 0.79
€ 13.49
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 14.28 / piece)
€ 14.28
plus VAT.
Only 9 Piece(s) available
Highlights & Details
EI 54/18.8 Print transformer VCM 16 VA
- This text is machine translated.
Technical specifications
- Product type
PCB mount transformer
- Output voltage
12 V AC
- Output voltage (number x voltage)
1 x 12 V AC
- Output current
1.33 A
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
16 VA
- Type
VCM 16/1/12
- Connection
Soldering
- Frequency
50 - 60 Hz
- Weight
0.42 kg
- Content
1 pc(s)
- Insulation class
VDE=B, UL=105
- Test voltage
500 V
- Test mark
C-UL-US, ENEC 10 (VDE)
- RoHS-compliant
Yes
- Max. ambient temperature
+40 °C
- Efficiency
76 %
16 VA
- Output voltage
12 V
Documents & Downloads
Datasheet
Datasheet 710717 BLOCK VCM 16/1/12 PCB mount transformer 1 x 230 V 1 x 12 V AC 16 VA 1.33 A
User & Safety Instructions
User & Safety Instructions 710717 BLOCK VCM 16/1/12 PCB mount transformer 1 x 230 V 1 x 12 V AC 16 VA 1.33 A
Description
Secondary terminal assignment : Pin 5 - 4
Hints
Dimension drawing and connector pin assignment see technical data sheet
