Chauvin Arnoux C106 Clamp meter adapter A/AC reading range: 0.1 - 1200 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 535.00 / piece)
€ 535.00
incl. VAT
Only 6 Piece(s) available
Highlights & Details
C-pliers - powerful clamp transformer for 1000 A !
- N/A
- Opening range of current clamps 53 mm
Technical specifications
- Transmission ratio (input/output): 1 A/1 mV
- Opening range of current clamps
53 mm
- Product type
Clamp meter adapter
- Type B
4 mm socket
Manufacturer's standards (no certificate)
- A AC reading range (min.)
0.1 A
- Amperage reading range AC (max.)
1200 A
- Basic accuracy
0.5 %
- Dim
(L x W x H) 45 x 216 x 111 mm
- Current reading
AC
- Reading category
CAT III 600 V
CAT IV 300 V
- Weight
550 g
- Output signal (max.)
1 V
- Max. frequency
10 kHz
- Width
216 mm
- Height
111 mm
- Length
45 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2199908 Chauvin Arnoux C106 Clamp meter adapter A/AC reading range: 0.1 - 1200 A
User & Safety Instructions
User & Safety Instructions 2199908 Chauvin Arnoux C106 Clamp meter adapter A/AC reading range: 0.1 - 1200 A
User & Safety Instructions 2199908 Chauvin Arnoux C106 Clamp meter adapter A/AC reading range: 0.1 - 1200 A
Description
The "C" series contains powerful clamp transformer for 1000 A. The round shape of the jaws and the uniform winding of the coil guarantee a high accuracy and minimum phase shift.
The optimum adjustment of the magnetic circuit through a pendulum-joint system and a patented support system for the progressive opening of the jaw plates facilitate the operation.
The 52mm diameter of the wrap allows CAT III 600V measurements to be made on most industrial and office building conductors.
This text is machine translated.
The optimum adjustment of the magnetic circuit through a pendulum-joint system and a patented support system for the progressive opening of the jaw plates facilitate the operation.
The 52mm diameter of the wrap allows CAT III 600V measurements to be made on most industrial and office building conductors.
This text is machine translated.
Scope of delivery
- 1 user manual
