Buy Diotec Rectifier PW4516 TO-247-2L 1600 V 45 A | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

Two black electronic components, labelled as 'TO-247', with three metallic terminals on a black background.

Two black electronic components, labelled as 'TO-247', with three metallic terminals on a black background.

Image similar

Diotec

Product type

Rectifier

Enclosure

TO-247-2L

Forward current I(F)

45 A

Reverse voltage U(R)

1600 V

Forward voltage U(F)

1.25 V

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 12 Nov

390 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 20

Total (€ 1.99671 / piece)

€ 2.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Rectifier

Our service for you

Technical specifications

Type wire-leadCasing TO-247-2L.Periodic Peak Reverse Voltage - VRRM 1600 VContinuous current - IFAV 45.00 AJunction temperature - Tjmax: °CForward voltage - VF 1.25 VIF 45.00 ASurge current - IFSM 450.00 AReverse current - IR 5,000 µAVR 1600 VLock layer capacity - CJ: PFVR V

Type: PW4516

Product type: Rectifier

Enclosure: TO-247-2L

Manufacturer: Diotec

Forward current I(F): 45 A

Reverse voltage U(R): 1600 V

Forward voltage U(F): 1.25 V

Reverse leakage current I(r): 5 µA

Mounting type: Through-hole mounting

I(FSM) 50Hz: 450 A

RoHS-compliant: Yes

Documents & Downloads

Datasheet

Datasheet 2808680 Diotec Rectifier PW4516 TO-247-2L 1600 V 45 A

User & Safety Instructions

User & Safety Instructions 2808680 Diotec Rectifier PW4516 TO-247-2L 1600 V 45 A
