econ connect Cable duct Total number of pins 4 Contact spacing: 2 mm CVG4/2 1 pc(s) Bulk
EAN:
Part number:
Item no:
Product type
Cable duct
Connector type
Enclosure
No. of rows
1
CS
2 mm
Total number of pins
4
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.03
100
33% = € 0.01
€ 0.02
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.03 / piece)
€ 0.03
plus VAT.
14-day return policy included
Highlights & Details
Crimp 1x4P straight RM 2.0
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 4
Technical specifications
- Packaging type
Bulk
- Product type
Cable duct
- Connector type
Enclosure
- No. of rows
1
- Connector system
wire-to-board
- CS
2 mm
- Pins per row
4
- Total number of pins
4
- Width
4.5 mm
- Nominal current
2 A
- Nominal current - rounded value
2 A
- Content
1 pc(s)
- Dim
(W x H) 4.5 mm x 6.85 mm
- Connection
Push-fit
- Case material
Nylon (NL)
- Manufacturer part #
CVG4/2
- Factory colour
White
- Nominal voltage
100 V
- Height
6.85 mm
- Max. temperature
85 °C
- Min. temperature
-25 °C
- Type
CVG4/2
Documents & Downloads
Datasheet
Datasheet 2860080 econ connect Cable duct Total number of pins 4 Contact spacing: 2 mm CVG4/2 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 2860080 econ connect Cable duct Total number of pins 4 Contact spacing: 2 mm CVG4/2 1 pc(s) Bulk
Description
Scope of delivery
- Content: 1 pcs.
- This text is machine translated.
