Electronic pressure controller in a black housing with a digital display and blue buttons. Front side shows a plug connection.

Electronic pressure controller in a black housing with a digital display and blue buttons. Front side shows a plug connection.

Image similar

FESTO

Product type

Flow sensor

Min. operating voltage

22 V DC

Max. operating voltage

26 V DC

Type

SFAH-5B-Q6S-PNLK-PNVBA-M8

Operating voltage

22 - 26 V DC

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Wed 18 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 395.00 / piece)

€ 395.00

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Technical specifications

Product type: Flow sensor

Type: SFAH-5B-Q6S-PNLK-PNVBA-M8

Min. operating voltage: 22 V DC

Max. operating voltage: 26 V DC

Operating voltage: 22 - 26 V DC

Features: LED indicator

Connector: Cable, M8 4-pin plug

Outputs: 2x PNP

Material: NBR

Material properties: rust-proof

Sealant: NBR

Enclosure material: PA

Nominal diameter: 6 mm

Media temperature (min.): 0 °C

Max. media temperature: 50 °C

Max. operating pressure: 10 bar

Accuracy ±: 0.2 %

Contact type: 1 breaker
1 maker

: IP40

Weight: 60 g

Min. ambient temperature: 0 °C

Max. ambient temperature: +50 °C

Content: 1 pc(s)

RoHS-compliant: Yes

Operating pressure (min.): 0.9 bar

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2803119 FESTO Flow sensor SFAH-5B-Q6S-PNLK-PNVBA-M8 8158414 Operating voltage (range): 22 - 26 V DC 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2803119 FESTO Flow sensor SFAH-5B-Q6S-PNLK-PNVBA-M8 8158414 Operating voltage (range): 22 - 26 V DC 1 pc(s)

Description

Flow sensor SFAH-5B-Q6S-PNLK-PNVBA-M8 approval=(* RCM Mark, * c UL US - Listed (OL)), CE mark (see declaration of conformity)=(* according to EU EMC directive, * according to EU RoHS-RL), KC mark=KC-EMC, Certificate issuing body=UL E322346, Material note=RoHS compliant

This text is machine translated.

Description

Flow sensor SFAH-5B-Q6S-PNLK-PNVBA-M8 approval=(* RCM Mark, * c UL US - Listed (OL)), CE mark (see declaration of conformity)=(* according to EU EMC directive, * according to EU RoHS-RL), KC mark=KC-EMC, Certificate issuing body=UL E322346, Material note=RoHS compliant

This text is machine translated.
