Name: FESTO PE converter 8625 PEN-M5 M5 -0.8 up to 8 bar 1 pc(s)
Brand: FESTO
SKU: 1894693
Availability: BackOrder

A black electromagnet with cable connection, mounted on a rectangular base.

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 309.00 / piece)

€ 309.00

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

PEN-M5

Technical specifications

Protection class: IP67
Cable length: 2.5 m.
Measurement size: Differential pressure, relative pressure
Mounting type: on mounting frame 2 n, with through hole
Operating pressure: 1 bar 8 bar
Max. Switching frequency: 70 Hz
Electrical connection: cable, open end, 3-wire
Pneumatic connection: M5
Material Housing: zinc die-cast
Switching status indicator: LED yellow

Type: PEN-M5

Operating medium: Compressed Air

Product type: PE converter

Min. switching pressure range: -0.8 bar

Max. switching pressure range: 8 bar

Switching pressure: -0.8 up to 8 bar

Media temperature (range): +60 °C (max)

Operating temperature: -20 up to +60 °C

Min. operating temperature: -20 °C

Max. operating temperature: +60 °C

Manufacturer part #: 8625

Operating voltage: 30 V

Fluid connection: M5

Weight: 240 g

Max. media temperature: +60 °C

Connection: M5

Connection: Open end cable

Operating medium: Compressed air

Material (details): Zinc diecast

Max. operating pressure: 8 bar

Operating pressure (min.): -1 bar

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1894693 FESTO PE converter 8625 PEN-M5 M5 -0.8 up to 8 bar 1 pc(s)

User & Safety Instructions

User & Safety Instructions 1894693 FESTO PE converter 8625 PEN-M5 M5 -0.8 up to 8 bar 1 pc(s)

Information

Information 1894693 FESTO PE converter 8625 PEN-M5 M5 -0.8 up to 8 bar 1 pc(s)

Description

PE-Converter PEN-M5 pneumatic electrical signal converter, switch for pressure, vacuum and differential pressure to 2 N-connection plate. Approval = RCM mark, CE mark (see declaration of conformity) = after EU EMC Directive, material note = (* copper and PTFE-free, * RoHS compliant), measurement size = (*), differential pressure, * Relative pressure measurement method = pneumatically-electric differential pressure switches

This text is machine translated.
