Finder 43.41.7.012.2000 PCB relay 12 V DC 10 A 1 change-over 1 pc(s)
Product type
PCB relay
Coil nominal voltage
12 V DC
Control mode
monostable, 1 coil
Contact type
1 change-over
Switching voltage (max.)
400 V AC
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 4.79 / piece)
€ 4.79
incl. VAT
14-day return policy included
Highlights & Details
Low print relay: series 43
- Contact spacing 3.2 mm
- This text is machine translated.
Our service for you
Technical specifications
- Relay protection RT II
- Product type
PCB relay
- Type
43.41.7.012.2000
- Coil nominal voltage
12 V DC
- Min. pick-up voltage
8.4 V DC
- Max. pick-up voltage
18 V DC
- Control mode
monostable, 1 coil
- Resistance (coil)
580 Ω
- Contact type
1 change-over
- Contact material
AgCdO
- Switching voltage (max.)
400 V AC
- Switching current (max.)
10 A
- Max. switching capacity
2500 VA
- Creepage distance (coil/clips)
10 mm
- Connection
Solder pins
- Durability
(AC/DC) 10 x 106 switching operations
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Length
30.2 mm
- Width
10.2 mm
- Height
15.4 mm
- Dim
(L x W x H) 30.2 x 10.2 x 15.4 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
DC-coil
- Nominal voltage (details)
12 V DC
- Nominal current (details)
10 A
- Switching current
10 A
Documents & Downloads
Datasheet
Datasheet 503106 Finder 43.41.7.012.2000 PCB relay 12 V DC 10 A 1 change-over 1 pc(s)
User & Safety Instructions
User & Safety Instructions 503106 Finder 43.41.7.012.2000 PCB relay 12 V DC 10 A 1 change-over 1 pc(s)
Description
PCB relay 10.2 mm wide.
Hints
Approvals UL, CSA, VDE
