Finder 48.61.7.024.1050 Crossbar switch 24 V DC 16 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Product type
Crossbar switch
Contact type
1 change-over
Nominal voltage
24 V DC
Switching voltage (max.)
400 V AC
Switching current (max.)
16 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 15.12
30
5% = € 0.75
€ 14.37
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Multiple: 10
Total (€ 15.12 / piece)
€ 151.20
plus VAT.
14-day return policy included
Highlights & Details
Coupling Relays
- 1 CHANGER 16 A / 250 V AC
- Coil voltage 24 V DC
- Contact material AgNi
- With integrated LED and EMC interference suppression
Technical specifications
- Product type
Crossbar switch
- Type
48.61.7.024.1050
- Min. pick-up voltage
19.2 V DC
- Max. pick-up voltage
36 V DC
- Response time
12 ms
- Fall time
4 ms
- Contact type
1 change-over
- Contact material
AgNi
- Nominal voltage
24 V DC
- Switching voltage (max.)
400 V AC
- Switching current (max.)
16 A
- Max. switching capacity
4000 VA
- Creepage distance (coil/clips)
8 mm
- Coil voltage rating
0.5 W
- Features
+ reverse polarity protection
+ diode
IP20
- Max. temperature
70 °C
- Min. temperature
-40 °C
- Length
75.3 mm
- Width
15.8 mm
- Height
78.6 mm
- Dim
(L x W x H) 75.3 x 15.8 x 78.6 mm
- Content
1 pc(s)
- Industrial packaging
Yes
- RoHS-compliant
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3702238 Finder 48.61.7.024.1050 Crossbar switch 24 V DC 16 A 1 change-over 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3702238 Finder 48.61.7.024.1050 Crossbar switch 24 V DC 16 A 1 change-over 1 pc(s)
Description
Coupling relays for DIN rail with screw connections
