Hazet 9037SPC Pneumatic rivet gun 6.3 bar
EAN:
Part number:
Item no:
Number
Total (€ 159.66 / piece)
€ 159.66
plus VAT.
14 days return policy included
Technical specifications
- Product type
Pneumatic rivet gun
- Air consumption
1 l/min
- Max. operating pressure
6.3 bar
- Operation pressure
6.3 bar
- Weight
1500 g
- Material
Metal
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 801522 Hazet 9037SPC Pneumatic rivet gun 6.3 bar
Description
Pneumatic/hydraulic-for Popnietarbeiten · Possible rivet sizes: 2.4 - 3.0 - 3.2 - 4.0 - 4.8 · 4 mouthpieces · With robust metal housing · Air consumption: 1 l/hub · Operating pressure: 6.3 bar · Sound pressure level Lp A 85 dB (A) · Pulling Force: 8700N · Incl. coupling socket, normal diameter 7.2 - with swivel joint for flexible use
Features
- Pneumatic / hydraulic - For pop rivets
- Possible rivet sizes: 24-30-32-40-48 mm
- 4 nose pieces (one nose piece pre-installed)
- With sturdy metal housing
- Tractive power: 8700 N
- Coupler plug with swivel joint for flexible operation
- Coupler plug: nominal size 72 (included)
- Working pressure (bar): 63
- Total length (for eClass): 270 mm
- Net weight: 15 kg
- Sound pressure level: 85 dB(A) Lp A
- Air requirement: 1 l/stroke(0 l/sec)
Hints
This text is machine translated.
