Buy HellermannTyton FKH80-HIR-BK-C1 Cable mount Screw fixing 151-16800 for ribbon cable, impact-resistant Black 1 pc(s) | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

Opened black razor with ridged handle and sharp blade.

Opened black razor with ridged handle and sharp blade.

Office desk with organised cables secured in cable management clips; demonstrates a tidy, efficient workspace organisation.

Cross-section of a cable entry with dimensions 'L', 'W2', and 'W'. Shows the structure and installation of the cable seal.

1/3

HellermannTyton

Product type

Cable mount

Fastening method

Screw fixing

Material

Polyamide 6.6

Features

for ribbon cable

impact-resistant

Min. temperature

-40 °C

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Mon 2 Nov

77 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 4.79 / piece)

€ 4.79

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Flat ribbon cable clamp screw

This text is machine translated.

Our service for you

Technical specifications

Flame-retardant according to UL94 HB (without adhesive)

Product type: Cable mount

Features: for ribbon cable
impact-resistant

Fastening method: Screw fixing

Material: Polyamide 6.6

Min. temperature: -40 °C

Max. temperature: +80 °C

Mounting Ø (min.): 3.10 mm

Mounting Ø (max.): 3.10 mm

Factory colour: Black

Halogen-free: Yes

Content: 1 pc(s)

Manufacturer part #: 151-16800

Dimensions: (L x W x W2) 86 x 25 x 22 mm

Suitable for: Rounded surfaces

RoHS-compliant: Yes

Type: FKH80-HIR-BK-C1

Material (details): Polyamide 6.6 modified impact resistant (PA66HIR)

Type: w/o adhesive

Operating temperature: -40 - +80 ºC, short-term - +105 °C (500 h)

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 547950 HellermannTyton FKH80-HIR-BK-C1 Cable mount Screw fixing 151-16800 for ribbon cable, impact-resistant Black 1 pc(s)

User & Safety Instructions

User & Safety Instructions 547950 HellermannTyton FKH80-HIR-BK-C1 Cable mount Screw fixing 151-16800 for ribbon cable, impact-resistant Black 1 pc(s)

Description

The flat ribbon cable clip can be attached with either high-quality acrylic tape or M3 screws. The handy quick lock/release allows you to quickly open and close the clamp. The flat ribbon cable clip is made of a high-quality, modified impact resistant polyamide 6.6 and can, therefore, be used in especially dry areas. The flat cable is routed and held securely due to the flat edges and the especially flexible wings.

Hints

Application: The flat ribbon cable clip is used wherever flat cables are applied, e.g. mechanical engineering and apparatus construction, in high-quality PCs and servers.

Description

The flat ribbon cable clip can be attached with either high-quality acrylic tape or M3 screws. The handy quick lock/release allows you to quickly open and close the clamp. The flat ribbon cable clip is made of a high-quality, modified impact resistant polyamide 6.6 and can, therefore, be used in especially dry areas. The flat cable is routed and held securely due to the flat edges and the especially flexible wings.

Hints

Application: The flat ribbon cable clip is used wherever flat cables are applied, e.g. mechanical engineering and apparatus construction, in high-quality PCs and servers.
