Idec HE2B-M200PN1 HE2B Series Acknowledgement button IP65 (EN 60529) 1 pc(s)
EAN:
Part number:
Item no:
Product type
Acknowledgement button
IP rating
IP65 (EN 60529)
Switch/button features
3-stage
Casing/button colour
Grey
Mounting type
Front mounting
Datasheet (PDF)
Number
Total (€ 40.67 / piece)
€ 40.67
plus VAT.
Technical specifications
- Product type
Acknowledgement button
- Switch/button features
3-stage
- Casing/button colour
Grey
- Mounting type
Front mounting
- Key type
Push buttons
- Material
Plastic
- Contact resistance
50 mΩ Maximum
- Resistance
Minimum: 100 MΩ Ω
- Min. temperature
-40 °C
- Max. temperature
+80 °C
- Durability
min 100,000 applications
IP65 (EN 60529)
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
HE2B Series
Documents & Downloads
Datasheet
Datasheet 3395425 Idec HE2B-M200PN1 HE2B Series Acknowledgement button IP65 (EN 60529) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3395425 Idec HE2B-M200PN1 HE2B Series Acknowledgement button IP65 (EN 60529) 1 pc(s)
Description
Enabling switch
This text is machine translated.
This text is machine translated.
Features
- 3-position enabling switch
Hints
Re switch position: content in parentheses describes the n/o and n/c contact constellation
