Joy-it SBC-PIR Motion sensor 1 pc(s) Compatible with (development kits): Arduino, Raspberry Pi®, BBC micro:bit
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.45
5
6% = € 0.32
€ 5.13
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.45 / piece)
€ 5.45
plus VAT.
Highlights & Details
Motion sensor PIR -6 meters range-
- Range continuously adjustable (max. 6m)
- Compatible with Raspberry and Arduino
Technical specifications
- Supply voltage between 3 - 5 volts
- Module interface 4 pins
- Detector chip on module BIS0001
- Detection angle 120 °
- Detection range max. 6m (3M standard)
- Continuous detection range
- By potentiometer
- Sets the sensitivity controller
- On the module board
- using a
- Phillips screwdriver
- Product type
Motion sensor
- Compatible with
Arduino
Raspberry Pi
BBC micro:bit
- Interfaces
Pin header
- Min. operating voltage
3 V
- Max. operating voltage
5 V
- Suitable for
Arduino
BBC micro:bit
Raspberry Pi®
- Tool type
Development kit
- Height
40 mm
- Length
19 mm
- Width
21 mm
- Internal ports
Pin header
- Weight
15 g
- Compatible with
Arduino
Raspberry Pi®
BBC micro:bit
Documents & Downloads
Datasheet
Datasheet 2306360 Joy-it SBC-PIR Motion sensor 1 pc(s) Compatible with (development kits): Arduino, Raspberry Pi®, BBC micro:bit
User & Safety Instructions
User & Safety Instructions 2306360 Joy-it SBC-PIR Motion sensor 1 pc(s) Compatible with (development kits): Arduino, Raspberry Pi®, BBC micro:bit
Description
The sensor on this module is
a pyroelectric infrared sensor,
which
detects a movement in the detection area of the Fresnel lens
and
then outputs a "HIGH" signal at the sensor output pin "SIG" for 3 seconds.
Then the signal returns
to the "LOW" state. The soldered potentiometer is used for
infinitely variable range adjustment.
With the help of this module and
a microcontroller such
as Raspberry Pi or Arduino, it can be used for security systems or automation, among other things.
This text is machine translated.
a pyroelectric infrared sensor,
which
detects a movement in the detection area of the Fresnel lens
and
then outputs a "HIGH" signal at the sensor output pin "SIG" for 3 seconds.
Then the signal returns
to the "LOW" state. The soldered potentiometer is used for
infinitely variable range adjustment.
With the help of this module and
a microcontroller such
as Raspberry Pi or Arduino, it can be used for security systems or automation, among other things.
This text is machine translated.
Scope of delivery
- Sensor
