Name: KOPOS LH 15X10_P1.0 Cable trunking Wiring duct (L x W x H) 1000 x 15 x 10 mm 1 pc(s) White (RAL 9003)
Brand: KOPOS
SKU: 3476363
Availability: InStock

A white, rectangular hollow structural section with clean edges, used in construction for support or framing.

Datasheet (PDF)

Fast track dispatch on Fri 16 Oct

197 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (1 m = € 1.79)

€ 1.79

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Electric installation channel LHD 15x10, white, with adhesive tape

Temperature resistance --5°C to +60°C
Flame resistant to 850°C.
Protection class: IP40
Self-adhesive tape

Technical specifications

Material: PVC - lead-free
Self-extinguishing: Yes, up to 30 s.
Temperature resistance --5°C+60°C
Flame resistant to 850°C.
Shock resistance 0.5 J
IP 40 protection class
Fire class A1-F
Internal area: 104 mm²
Distance between the perforated base 200 ±20 mm, Ø 4.5 mm
Length tolerance ±10 mm
Weighs 0.08 kg/m.
Mechanical protection according to ČSN EN 50102: IK06
According to the standard: ČSN EN 50085-1 ed. 2:06+A1:14, ČSN EN 50085-2-1:07+A1:12

Product type: Cable trunking

Component: Wiring duct

Supplied length: 1 m

Content: 1 pc(s)

Factory colour: White (RAL 9003)

Dim: (L x W x H) 1000 x 15 x 10 mm

Length: 1000 mm

Width: 15 mm

Material: PVC

Height: 10 mm

Documents & Downloads

Datasheet

Datasheet 3476363 KOPOS LH 15X10_P1.0 Cable trunking Wiring duct (L x W x H) 1000 x 15 x 10 mm 1 pc(s) White (RAL 9003)

User & Safety Instructions

User & Safety Instructions 3476363 KOPOS LH 15X10_P1.0 Cable trunking Wiring duct (L x W x H) 1000 x 15 x 10 mm 1 pc(s) White (RAL 9003)

Description

Intended for the installation of low voltage cables.
Suitable for wall or ceiling mounting.
Double lock on the lid increases the rigidity of the channel.

This text is machine translated.

Features

Intended for the installation of low voltage cables
Suitable for wall or ceiling mounting
Double lock on the lid increases the rigidity of the channel and even stronger fixing of the lid
Installation in areas where flammable gases and vapors hazards are possible (hazard zone 2)
Installation in areas where dust explosion hazards occur (danger zone 22)
Adhesive tape on the back side serves for temporary fixing of the duct before the final mounting on the surface.

Scope of delivery

1 x 1 m Channel

Description

Intended for the installation of low voltage cables.
Suitable for wall or ceiling mounting.
Double lock on the lid increases the rigidity of the channel.

This text is machine translated.

Features

Intended for the installation of low voltage cables
Suitable for wall or ceiling mounting
Double lock on the lid increases the rigidity of the channel and even stronger fixing of the lid
Installation in areas where flammable gases and vapors hazards are possible (hazard zone 2)
Installation in areas where dust explosion hazards occur (danger zone 22)
Adhesive tape on the back side serves for temporary fixing of the duct before the final mounting on the surface.
