Name: LAPP ÖLFLEX® CLASSIC 100 CY Control lead 3 G 1 mm² Transparent 35221-50 50 m
Brand: LAPP
SKU: 1029378
Availability: SoldOut

LAPP ÖLFLEX® CLASSIC 100 CY Control lead 3 G 1 mm² Transparent 35221-50 50 m-0

A close-up of a Lapp cable with text: 'LAPP KABEL STUTTGART ÖLFLEX CLASSIC 100 CY'. Various coloured wires are visible.

1/2

Product type

Control lead

No. of leads

3 G

Cross section (each core)

1 mm²

Cable type

ÖLFLEX® CLASSIC 100 CY

Outside Ø

8.20 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (1 m = € 2.60)

€ 129.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Ölflex ® CLASSIC 100 CY PVC control cable

Color-coded
EMC-conforming

Technical specifications

Product type: Control lead

No. of leads: 3 G

Content: 50 m

Cross section (each core): 1 mm²

Cable features: Shielded

Cable type: ÖLFLEX® CLASSIC 100 CY

Outside Ø: 8.20 mm

Packaged: Yes

Wire ID code: Coloured according to VDE 0293 or VDE 0293-308

Type: Round

Bend radius (no. of ODs for fixed installation): 6

Bend radius (no. of ODs for flexible installation): 20

Halogen-free: No

Manufacturer part #: 35221-50

Factory colour: Transparent

Insulation material: PVC

Core layout: Finely stranded

Material (details): PVC

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Certification marks: In accordance with: IEC 60227-5; HD 21.5 S3; VDE 0281 Part 5 HD 21.13 S1; VDE 0281 Part 13

Number-coded: No

Test voltage: 4 kV

Cross section: 3 G 1 mm²

Max. temperature range (flexible installation): +70 °C

Min. temperature range (flexible installation): -5 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: ÖLFLEX CLASSIC 100 CY 3G1

Documents & Downloads

Datasheet

Datasheet 1029378 LAPP ÖLFLEX® CLASSIC 100 CY Control lead 3 G 1 mm² Transparent 35221-50 50 m

Description

Used mainly at those places, where electrical interfering fields, caused e.g. by electric motors driven by frequency converters can distort the signal transmission.
Machine and plant engineering, conveying and transportation systems, heating and air-conditioning technology, office machines and data processing systems.
The transparent outer sheath protects the braid against contamination and mechanical damages. High insulation safety through 4 kV test voltage.
