Buy LAPP ÖLFLEX® SMART 108 Control lead 7 G 0.75 mm² Grey 11070099/500 500 m | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

A cable with the inscription 'LAPP KABEL STUTTGART ÖLFLEX SMART 100 VDE-Reg. No. 8690' and visible cores in various colours.

A cable with the inscription 'LAPP KABEL STUTTGART ÖLFLEX SMART 100 VDE-Reg. No. 8690' and visible cores in various colours.

Image similar

LAPP

Product type

Control lead

No. of leads

7 G

Cross section (each core)

0.75 mm²

Cable type

ÖLFLEX® SMART 108

Outside Ø

7.30 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 12 Nov

67 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Set(s)

Total (1 m = € 1.55)

€ 775.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Ölflex ® SMART 108 PVC control cable

Number coded
Flame-resistant according to IEC 60332-1-2
High security, test voltage 4 kV

Technical specifications

Product type: Control lead

No. of leads: 7 G

Content: 500 m

Cross section (each core): 0.75 mm²

Cable features: Flexible

Cable type: ÖLFLEX® SMART 108

Outside Ø: 7.30 mm

Packaged: Yes

Wire ID code: Black wires with white numbering (VDE 0293)

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 15

Halogen-free: No

Manufacturer part #: 11070099/500

Factory colour: Grey

Insulation material: PVC

Insulation: PVC

Core layout: Finely stranded according to DIN EN 60228 (VDE 0295), Class 5/IEC 60228 Class 5

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Certification marks: VDE-Reg. No. 8639

Number-coded: Yes

Test voltage: 4000 V

Cross section: 7 G 0.75 mm²

Suited for cable carriers: No

Max. temperature range (flexible installation): +70 °C

Min. temperature range (flexible installation): -5 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 11070099/500

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 1544000 LAPP ÖLFLEX® SMART 108 Control lead 7 G 0.75 mm² Grey 11070099/500 500 m

User & Safety Instructions

User & Safety Instructions 1544000 LAPP ÖLFLEX® SMART 108 Control lead 7 G 0.75 mm² Grey 11070099/500 500 m

Description

SMART: no more than necessary - the basic version of a flexible control cable by Lapp. The inner sheath layer made of regeneriertem PVC with unchanged high quality of the type TM2 relieves the environment. For fixed laying as well as also for flexible applications with free, not constantly recurring movement without tensile stress. Mainly in dry, moist or wet rooms at normal mechanical load. Application in mechanical engineering, plant construction, painting, heating and air-conditioning technology, power plant technology. Optimised, small outer-Ø and this reduced space requirement. High insulation safety through 4 kV test voltage. During production, free from paint-wetting impairment substances (LBS-free / silicone), making it suitable for painting.

This text is machine translated.

Description

SMART: no more than necessary - the basic version of a flexible control cable by Lapp. The inner sheath layer made of regeneriertem PVC with unchanged high quality of the type TM2 relieves the environment. For fixed laying as well as also for flexible applications with free, not constantly recurring movement without tensile stress. Mainly in dry, moist or wet rooms at normal mechanical load. Application in mechanical engineering, plant construction, painting, heating and air-conditioning technology, power plant technology. Optimised, small outer-Ø and this reduced space requirement. High insulation safety through 4 kV test voltage. During production, free from paint-wetting impairment substances (LBS-free / silicone), making it suitable for painting.

This text is machine translated.
