Leuze Electronic One-way light barrier LE46C/4P-M12 50127033 Receiver Light-ON, Dark-ON 1 pc(s)
EAN:
Part number:
Item no:
Product type
One-way light barrier
Functions
Light-ON
Dark-ON
Max. operating voltage
30 V DC
Connector
M12 (4-pin)
Type
LE46C/4P-M12
Datasheet (PDF)
Number
Total (€ 147.05 / piece)
€ 147.05
plus VAT.
Technical specifications
- Product type
One-way light barrier
- Type
LE46C/4P-M12
- Model
Receiver
- Functions
Light-ON
Dark-ON
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Outputs
2x PNP Antivalent
- Switching frequency
500 Hz
- Connector
M12 (4-pin)
- Transmitter type
LED red
- Wavelength
630 nm
150 m
IP67/IP69K
- Min. temperature
-40 °C
- Max. temperature
+60 °C
- Width
20.5 mm
- Height
77.4 mm
- Depth
44 mm
- Dim
(W x H x D) 20.5 x 77.4 x 44 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1581241 Leuze Electronic One-way light barrier LE46C/4P-M12 50127033 Receiver Light-ON, Dark-ON 1 pc(s)
Description
Robust plastic housing with degree of protection IP67 and IP 69K.
This text is machine translated.
This text is machine translated.
Hints
For more information on this 50127033, please refer to its datasheet under 'downloadable documents'
