Manhattan 178433 USB-Kit Barcode scanner Corded 1D CCD Black Hand-held USB
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 77.30 / piece)
€ 96.64
-20 %
€ 77.30
plus VAT.
Manhattan Linear CCD Barcode Scanner, 50 cm Scan Depth, Rugged Housing, USB
Highlights & Details
- Keyboard Wedge Decoder displays data as if directly entered from keyboard
- Detects many popular symbologies including UPC, EAN, 1D barcodes, ASCII, GS1 DataBar Family and more
Technical specifications
- Product type
Barcode scanner
- Type
178433 USB-Kit
- Type
Hand-held
- Scanning technology
CCD
- Readable code types
1D
- Reading distance (max.)
500 mm
- Scanning confirmation
Acoustic
LED
- Scan rate
500 Scans/s
- Cordless scanning
Corded
- Range of use
Manufacturing
- Factory colour
Black
- Interfaces
USB
- Cable length
1.50 m
- Protection class
IP54
- Width
70 mm
- Height
180 mm
- Depth
70 mm
- Weight
150 g
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 806698 Manhattan 178433 USB-Kit Barcode scanner Corded 1D CCD Black Hand-held USB
User & Safety Instructions
User & Safety Instructions 806698 Manhattan 178433 USB-Kit Barcode scanner Corded 1D CCD Black Hand-held USB
Description
Improve speed, accuracy and productivity.
Manhattan Linear CCD Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts, and has a rugged impact-resistant housing for years of reliable service of reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. With a scan rate of 500 scans per second and an accurate read range of up to 500 mm (20 in.), this model offers a high-performance, all-purpose daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.
Manhattan Linear CCD Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts, and has a rugged impact-resistant housing for years of reliable service of reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. With a scan rate of 500 scans per second and an accurate read range of up to 500 mm (20 in.), this model offers a high-performance, all-purpose daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.
Features
- Standards and Certifications
- FCC
- CE
- RoHS
- General
- Light source: 632nm, visible red LED
- Scanner range: 500 mm
- Resolution: 0.1 mm (4 mil) @ PCS 0.9
- Reading indicator: tone and LED
- Ambient light: 100,000 lux maximum (sunlight)
- Scan rate: Smart detection, up to 500 scans/second
- Interface: KBW / RS232 / USB (HID or Virtual Comport)
- Switch: trigger
- Code Support
- UPC/EAN/JAN, EAN128 Code, Code 39, Code 39 Full ASCII, Code 32/ Italian Pharmacy, Code 128, Codabar/MW7, Interleave 25, Industrial 25, Matrix25, MSI/PLESSEY, Telepan, Code 93, Code 11, China Postage, Code26, LCD25, GS1 DataBar (RSS code)
- Physical
- Dimensions, scanner: 18 x 7 x 7 cm (7 x 2.76 x 2.76 in.)
- Weight: scanner 0.15 kg (0.33 lbs.)
- Operating temperature: 0 – 50°C (32 – 122°F)
- Storage temperature: -20 – 60°C (-4 – 158°F)
- Relative humidity: 20 – 95% (non-condensing)
- Housing: ABS and rubber
- Sealing: IP54
- Electrical
- Supply voltage: DC +5 V +/- 5%
- Current draw: 70 mA
Scope of delivery
- Long Range Linear CCD Barcode Scanner
- User manual
