Name: Metrel MI 3394 EU VDE tester
Brand: Metrel
SKU: 2542956
Availability: BackOrder

A digital multifunctional measuring device with a colour display, various buttons and connections for measuring electrical parameters.

EAN:

Part number:

Item no:

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 8,365.00 / piece)

€ 8,365.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

CE MultiTesterXA

CE certification of appliances; safety testing of appliances; custom auto sequences; large SD card; PC software for reporting.

Technical specifications

High voltage, programmable (AC/DC);Continuity tests;Insulation resistance measurement;Spare leakage current;Differential leakage current;Contact leakage current;PE leakage current;Discharge time;Functional tests (power P/S/Q, voltage, current, cos fi, frequency, ThdU, ThdI, PF).Protective conductor / resistance Max. Test current 200 mA two-wireMax. Test current 10 A two-wireMax. Test current 10 A two-wire (voltage drop)Max. Test current 25 A two-wireMax. Test current 200 mA four-wireMax. Test current 4 A 4-wireMax. Test current 10 A four-wireMax. Test current 25 A - 4-wireInsulating resistance Test voltage 50VTest voltage 10VTest voltage 250VTest voltage 500VTesting voltage: 1000VDCRamp voltage test/varistor testAutomatic dischargeLeakage current IPE differential current methodContact currentLeakage currentPE leakage current (direct)Hipot resistance test Test voltage 1000 VAC (500VA)Test voltage 1890 VAC (500VA)Test voltage 2500 VAC (500VA)TEST VOLTAGE 100…2500 VAC (500 VA) RAMPTest Voltage 100 - 5100 VAC (250 VA)TEST VOLTAGE 100… 5100 VAC (500 VA) RAMPTEST VOLTAGE 100… 5100 VAC (500 VA) COMBUSTIONTest voltage 500… 6000 VDC RAMPProgrammable test voltage

Product type: VDE tester

: Manufacturer's standards (no certificate)

Interfaces: Bluetooth®
RS232
1x Ethernet
USB

Dim: (L x W x H) 435 x 292 x 155 mm

Weight: 17 kg

Reading range (VDE): Differential current
Earth leakage current
Frequency
Earth leakage resistance
Leakage current
Touch voltage
Resistance
Insulation resistance
Power
Current
Voltage
Show more

Display type: LCD Touch

Width: 292 mm

Height: 155 mm

Length: 435 mm

Test procedure: automated

Memory: Yes

Type: MI 3394 EU

Features: built-in colour touchscreen
incl. software
remotely controllable

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2542956 Metrel MI 3394 EU VDE tester

Description

The MI 3394 CE MultiTesterXA is a portable measuring device for electrical safety testing and CE certification of electrical devices, machines and control cabinets during production. The MES Manager PC software enables the upload of automated test sequences and projects, the download of test results to the PC, the automatic data storage in a file and the printing of test reports. The CE MultiTesterXA is the perfect instrument for electrical safety testing in the most demanding environments such as laboratories, automated production lines or specialist workshops.

This text is machine translated.

Features

Data Management: The instrument has a unique user-friendly data management facility and state-of-the-art Memory OrganizerTest connections: Different test connections allow the user to choose between performing individual tests or auto sequences via a test socket.Automatic checks: Auto sequences can be intuitively combined with the sequence manager present in the device.MicroSD: Support for microSD memory cards (8GB supplied with device) up to 32GB.Color display 3.4" color LCD with touch screen.Hi-pot: High voltage AC (5.1 kV at 500 VA) and DC (6 kV) testing.Continuity: 4 - conductor continuity test with selectable test current (0.2 A, 4 A, 10A, 25A), enables precise measurements.Communication: 4 - RS232, USB, Ethernet and Bluetooth communication interfaces allow you to download, upload data and remotely control the meter.Multi-system testing: The meter can be used on TT, TN, IT and 115V supply systems.

Scope of delivery

Measuring device CE MultiTester XAHigh-voltage test gun with 2 m cable, 2 pieces.Continuity test cable 2.5 m, 2 piecesContinuity test cable 1.5 m, 2 piecesInsulation test lead, red 2.5 mInsulation test lead, black 2.5 mCrocodile clip, black, 3 piecesCrocodile clip, red, 2 piecesTest lead discharge timePower cable;Bag for accessoriesCalibration certificateRS232 cableUSB cableCD with operating instructions (full version)PC SW Meterl ES Manager
