Metz Connect SAR1 AP N/A
EAN:
Part number:
Item no:
Number
Total (€ 42.99 / piece)
€ 42.99
incl. VAT
Only 1 Piece(s) available
Highlights & Details
BTR SAR 1 AP Current Start-Up Relay
- Remote switching via call signal
- Wall mounting
- Does not need a separate power supply
Technical specifications
- Product type
Power-on relay
- Dim
(W x H x D) 65 x 80 x 27 mm
- Factory colour
Oyster white
- Width
65 mm
- Height
80 mm
- Depth
27 mm
- Switching capacity
2000 VA AC 240 W at <30 V/DC 50 W at >30 V/DC
- Switching voltage
max. 250 V /AC
- Switching current
max. 8 A (6 A continuous)
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 930508 Metz Connect SAR1 AP N/A
User & Safety Instructions 930508 Metz Connect SAR1 AP N/A
Description
The SAR switches an external signal generator (e.g. bell, horn or lamp) through a contact with its own or separate power supply when a control voltage is applied (e.g. incoming call voltage of a telecommunications connection line). With the in-built switch the external signalling can be switched on or off. The SAR 1 is connected to a telecommunications line and is controlled by the call voltage. The switching takes place via the terminals Lb and W of the TAE-connection socket or alternatively also at the terminals La and Lb (parallel switching) of the connection line. The SAR 1 responds only to the call voltage and not to the dial tone (IWV).
Features
- Surface-mounted design
- In-built switch for switching on and off the external signalling
- Connection at telecommunications connection line or direct-voltage signal source
