Monacor RBT-35SR Ribbon tweeter 12 W 7 Ω
EAN:
Part number:
Item no:
Number
Total (€ 315.00 / piece)
€ 315.00
incl. VAT
Only 10 Pair available
Technical specifications
- Impedance (Z): 7 Ohm
- Resonant frequency (fs): -
- Max. Frequency range 1100 30000 Hz
- Recv. Cut-off frequency (Fmax.) (12 dB/oct):> 3000 Hz
- Maximum load-carrying capacity: 25WMAX
- Nominal load (P): 12WRMS
- Avg. Schalldr. (1W/1m): 96 dB
- Product type
Ribbon tweeter
- RMS capacity
12 W
- Max. load
25 W
- Min. frequency
1100 Hz
- Max. frequency
30000 Hz
- Frequency range
1100 Hz - 30000 Hz
- Sound pressure
96 dB
- Impedance
7 Ω
- Recess depth
10.1 cm
- Weight
520 g
- Width
11 cm
- Height
9.8 cm
- Speaker size (cm)
98 cm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1416979 Monacor RBT-35SR Ribbon tweeter 12 W 7 Ω
Description
The new high-end tweeter RBT connects you-35SR include the group of real ribbon tweeter.
These are characterised by an extremely light diaphragm from an aluminum foil, which completely from the audio signal flows through.
The low impedance this membrane is a built-in, high-quality transformer to amplifier critical 5-8 ohms is transformed.
Ribbon tweeter impress through an extremely fine resolution, brilliant sound in the treble range.
Through continuous further development, these ribbon nowadays, depending on the type, starting from a cut-off frequency of 2500 Hz can be used and are the choice when it comes to most significant hi-fi speakers or studio monitors.
Ribbon must not be operated without frequency point!
This text is machine translated.
These are characterised by an extremely light diaphragm from an aluminum foil, which completely from the audio signal flows through.
The low impedance this membrane is a built-in, high-quality transformer to amplifier critical 5-8 ohms is transformed.
Ribbon tweeter impress through an extremely fine resolution, brilliant sound in the treble range.
Through continuous further development, these ribbon nowadays, depending on the type, starting from a cut-off frequency of 2500 Hz can be used and are the choice when it comes to most significant hi-fi speakers or studio monitors.
Ribbon must not be operated without frequency point!
This text is machine translated.
Features
- Selected, 25WMAX, 12WRMS, 7 Ohm
- Real ribbon with neodymium magnet system and transformer
- By horn attachment very high sound pressure and constant bundling behavior
- Brilliant, high-definition high-range playback
- Smooth, non-embossed aluminum sandwich diaphragm 9 x 60 x 0.015 mm
- Over 18 dB filter can be used starting from 2500 Hz
- Horn with mounting flange and protective grille
