Name: Murrelektronik MB Cap Ultra 3/24 7s 85460 Energy storage
Brand: Murrelektronik
SKU: 512870
Availability: InStock

Highlights & Details

Murrelektronik MB Cap Ultra 3/24 7s 85460 Energy storage

Maintenance-free by long-lasting ultra capacitors
Microcontroller-supported charging and discharging of the ultra capacitors
Monitoring of operation and charging status via potential-free contacts and LEDs

Technical specifications

Input voltage: 24 V DC

Product type: Energy storage

Nominal power: 72 VA

Output: Spring-loaded terminal

Input voltage (max.): 26.4 V DC

Min. input voltage: 20.4 V DC

Output voltage (max.): 24 V DC

Output voltage (min.): 24 V

Dim: (W x H x D) 60 x 100 x 125 mm

Rechargeable battery capacity (details): 0.5 kJ

Connections: Cage-clamps

Output current (details): 3 A

Weight: 0.6 kg

Width: 60 mm

Height: 100 mm

Depth: 125 mm

Type: MB Cap Ultra 3/24 7s

Features: Capacitive energy storage

Bridging time, max load: 7 s

Output voltage: 24 V DC

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 512870 Murrelektronik MB Cap Ultra 3/24 7s 85460 Energy storage

User & Safety Instructions

User & Safety Instructions 512870 Murrelektronik MB Cap Ultra 3/24 7s 85460 Energy storage

Description

The DC-Buffermodul of Typical series MB Cap Ultra has a ultra condensator in interior of casing as energy storage. This condensator is charged in normal mode by an externally regulated DC-power. During an interruption in DC-supply, the energy of ultra condensator is released with regulation. The charge is fed by buffer module till discharge The buffer time depends on charging status of condensator and the discharge current.

Features

Buffer time 7 s in 3A Last
24 V Input-/output voltage
Contact
Maintenance free for life - as lead free
cage-clamps for tool-free wiring

Description

The DC-Buffermodul of Typical series MB Cap Ultra has a ultra condensator in interior of casing as energy storage. This condensator is charged in normal mode by an externally regulated DC-power. During an interruption in DC-supply, the energy of ultra condensator is released with regulation. The charge is fed by buffer module till discharge The buffer time depends on charging status of condensator and the discharge current.
