Pepperl+Fuchs Sensor VDM28-8-L1-IO/33/110/115b/122 297904 Push-pull (inverted) 1 pc(s)

A rectangular green and black electrical sensor with cable connection, likely designed for object detection.
Image similar
Product type
Sensor
Max. operating voltage
30 V DC
Connector
Cable, M12 3-pin plug
Type
VDM28-8-L1-IO/33/110/115b/122
Model
Push-pull (inverted)
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Thu 5 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 825.00 / piece)
€ 825.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

  • Light spot diameter: 10 mm at a distance of 8 m at 20°C, Function display: 2 yellow LEDs for Switch Status
Product type

Sensor

Type

VDM28-8-L1-IO/33/110/115b/122

Model

Push-pull (inverted)

Operating voltage

30 V DC

Min. operating voltage

10 V DC

Max. operating voltage

30 V DC

Operating voltage

10 - 30 V DC

Outputs

IO link

Connector

Cable, M12 3-pin plug

Cable length

15.00 cm

Enclosure material

Plastic

Acrylonitrile butadiene styrene

Transmitter type

Laser diode

Laser class

1

Wavelength

660 nm

8 m

Features

LED indicator

IP67

Width

25.8 mm

Height

88 mm

Depth

54.6 mm

Dim

(W x H x D) 25.8 x 88 x 54.6 mm

Content

1 pc(s)

Documents & Downloads

Datasheet

Datasheet 2130893 Pepperl+Fuchs Sensor VDM28-8-L1-IO/33/110/115b/122 297904 Push-pull (inverted) 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2130893 Pepperl+Fuchs Sensor VDM28-8-L1-IO/33/110/115b/122 297904 Push-pull (inverted) 1 pc(s)

Conformity certificate

Conformity certificate 2130893 Pepperl+Fuchs Sensor VDM28-8-L1-IO/33/110/115b/122 297904 Push-pull (inverted) 1 pc(s)

Description

Universal distance sensor, measurement to object, IO-Link interface, measurement methods, PRT, Range 8 m laser light red, laser class 1, push-pull output, analog output, fixed cable with M12 connector

This text is machine translated.

Hints

For more information on this 297904, please refer to its datasheet under 'downloadable documents'
