Name: Phoenix Contact 1713066 Screw terminal 2.50 mm² Number of pins 8 Green 50 pc(s)
Brand: Phoenix Contact
SKU: 773410
Availability: InStock

Green, five-way printed circuit board terminal block with metal contacts at the bottom and side cable openings. It is used for electrical connection.

Image similar

Product type

Screw terminal

5.00 mm

Pins per row

Number of pins

Connection

Screw terminal

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

21 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 50 pc(s))

Set(s)

Total (€ 3.60 / piece)

€ 179.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block SMKDS 3/ 8

Content 50 pc(s)

Technical specifications

Type: SMKDS 3/ 8

Product type: Screw terminal

Features: + extractor sleeve

CS: 5.00 mm

Pins per row: 8

Number of pins: 8

Series: SMKDS

Stripping length (max.): 8.00 mm

Connection: Screw terminal
Print

Nominal current: 24 A

Cross section (flexible) (min.): 0.20 mm²

Nominal current - rounded value: 24 A

Cross section (inflexible) (min.): 0.20 mm²

Cross section (flexible) (max.): 2.50 mm²

Cross section (inflexible) (max.): 4.00 mm²

AWG (min.): 24

Connector orientation: At an angle (to the PCB)

AWG max.: 12

Contact material: Tin plated

Factory colour: Green

Actuation direction: At an angle (to the PCB)

Manufacturer part #: 1713066

Industrial packaging: Yes

Content: 50 pc(s)

Nominal voltage: 400 V

Height: 18.00 mm

Length: 16.00 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 773410 Phoenix Contact 1713066 Screw terminal 2.50 mm² Number of pins 8 Green 50 pc(s)

User & Safety Instructions

User & Safety Instructions 773410 Phoenix Contact 1713066 Screw terminal 2.50 mm² Number of pins 8 Green 50 pc(s)

Description

PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 8, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 35 °, Color: green, The article can be aligned to create different nos. of positions!
