ElectromechanicsRelaysSolid State RelaysSolid State Relays

Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

EAN:
Part number:
Item no:
Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)-0
Packaging type
Piece
Product type
SSR
Control voltage (min.)
3 V DC
Control voltage (max.)
12 V DC
Switching voltage (max.)
48 V DC
Datasheet (PDF)
Dispatches on Thu 29 Oct
2 Set(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 12 pc(s))
Total (€ 13.75 / piece)
€ 164.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
Only 2 Set(s) available
14-day return policy included
Report legal concerns

Technical specifications

Packaging type

Piece

Product type

SSR

Type

SSL1D101JD

Switching type

DC circuit

Connection

Jack connector

Control voltage (min.)

3 V DC

Control voltage (max.)

12 V DC

Control voltage range

3 - 12 V DC

Switching voltage (min.)

1 V DC

Switching voltage (max.)

48 V DC

Output voltage (min.)

1 V DC

Output voltage (max.)

48 V DC

Max. output current

0.1 A

Contact type

1 maker

Width

6.2 mm

Content

12 pc(s)

1

TRUE

0.1 A

DC

0.1 A

FALSE

Documents & Downloads

Datasheet

Datasheet 2923836 Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

Datasheet 2923836 Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

User & Safety Instructions

User & Safety Instructions 2923836 Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

Information

Information 2923836 Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

Information 2923836 Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

Information 2923836 Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

Information 2923836 Schneider Electric SSR SSL1D101JD Switching voltage (max.): 48 V DC DC circuit 12 pc(s)

Description

Zelio relay Pluggable semi-conductor relay as component for mounting in a separate plug-in socket in slim design of 6.2 mm. Controlled in the voltage range 3-12 VDC. On the output side, voltage 1-48 VDC up to 0.1 A can be switched single-pole. The switching behavior is direct current switching, carried out by transistors and corresponds to a normally open contact. A suitable base would be SSLZRA1 or SSLZVA1.

This text is machine translated.
