Image similar
Image similar
Self Electronics SLT30-24VFG LED transformer Constant voltage 30 W 0 - 1.25 A 24 V DC not dimmable, Approved for use on
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.84
3
4% = € 0.95
€ 20.89
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.84 / piece)
€
Highlights & Details
SLT30-24VFG
- Constant voltage
- 24 V DC
- 0 - 1.25 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
- Dim
(L x W x H) 247 x 30 x 16 mm
- Factory colour
White
Blue
- Output voltage (max.)
24 V DC
- Test mark
SELV; MM
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Operating voltage
230 V AC
- Protection class
II
- LED driver features
not dimmable
Approved for use on furniture
Surge protection
IP20
- Connection
Screw terminal
- Max. power
30 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
0 A
- Input voltage (max.)
264 V AC
- Min. input voltage
198 V AC
- Weight
125 g
- Power range
30 W (max)
- Width
30 mm
- Height
16 mm
- Length
247 mm
- Max. temperature
+45 °C
- Min. temperature
-20 °C
Documents & Downloads
Datasheet
Datasheet 1646016 Self Electronics SLT30-24VFG LED transformer Constant voltage 30 W 0 - 1.25 A 24 V DC not dimmable, Approved for use on
User & Safety Instructions
User & Safety Instructions 1646016 Self Electronics SLT30-24VFG LED transformer Constant voltage 30 W 0 - 1.25 A 24 V DC not dimmable, Approved for use on
Description
With the 30-watt series SLT30-VLG - it self-electronics, we carry out high-quality new 12 volt and 24 volt constant voltage power supplies in the program. Thanks to optimized circuit topology and efficient production processes, the power supply products via a very good price-performance ratio. The low power consumption of the power supplies in the standby mode and a start-up period of time in 500 ms corresponds to the requirements of the ERP Guidelines. Even under unfavorable operating conditions and maximum case temperature of 75 °C. the self-LED power supplies a nominal service life of 35,000 hours. Protection against electrical shock ensures an SELV output less than 60 V. For additional security, protection against interruption, short circuit, overload and overheating. The MM-character allows mounting on materials with unknown ignition properties, a use as an independent operating device is possible. The series meets all popular EN-standards.
This text is machine translated.
This text is machine translated.
Features
- Independent operating device
- Protection class II, SELV output
- Flicker-free design
- Constant voltage
- IP20
- Protected against overload, short-circuit, over-voltage and temperature protection
- EN 61347-1, EN 61347-2-13, EN55015, EN61000-3-2, etc.
- For LED applications
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
