SEPA MFB50E12 Axial fan 12 V DC 14.3 m³/h (L x W x H) 50 x 50 x 10 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
12 V DC
No. of wires
2
Type of bearing
Ball bearing
Air flow rate
14.3 m³/h
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 15.12
3
5% = € 0.75
€ 14.37
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 15.12 / piece)
€
Technical specifications
- MTBF: 280000 h
- Product type
Axial fan
- Type
MFB50E12
- Nominal voltage
12 V DC
- No. of wires
2
- Max. current consumption
60 mA
- Type of bearing
Ball bearing
- Rotational speed
4800 U/min
- Noise emission (max.)
25 dB
- Air flow rate
14.3 m³/h
- Connection
Open end cable
- Cable length
29.00 cm
- Pressure (max.)
26.9 Pa
- Factory colour
Black
- Material
PBT
(L10) 95000 h
- Min. temperature
-40 °C
- Max. temperature
+80 °C
- Length
50 mm
- Width
50 mm
- Height
10 mm
- Dim
(L x W x H) 50 x 50 x 10 mm
- Temperature range
-40 - +80 °C
Documents & Downloads
Datasheet
Datasheet 1664493 SEPA MFB50E12 Axial fan 12 V DC 14.3 m³/h (L x W x H) 50 x 50 x 10 mm
User & Safety Instructions
User & Safety Instructions 1664493 SEPA MFB50E12 Axial fan 12 V DC 14.3 m³/h (L x W x H) 50 x 50 x 10 mm
Description
This high tech mini exhaust is used for industrial or automotive purposes and has a remarkable flow rate despite its small size and low power consumption. Other features of this exhaust are its extremely rugged and dimensionally stable casing made of fibre-reinforced PBT, ball bearings made of special steel, printed board made of polyester and absolute reliability by 100% burn-in.
