Spelsberg 72212001 Rail mounted PSU (DIN) 0.63 A 15.2 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Total (€ 35.29 / piece)
€
Technical specifications
- Product type
Rail mounted PSU (DIN)
- Input voltage
85 V/AC - 264 V AC
- Max. output current
0.63 A
- Output current (max.) - rounded
630 mA
15.2 W
- No. of outputs
1 x
- Connection
Screws
- Dim
(L x W x H) 54.5 x 17.5 x 90 mm
- Output voltage (max.)
29 V DC
- Output voltage (min.)
21.6 V DC
- Manufacturer part #
72212001
- Content
1 pc(s)
- Width
17.5 mm
- Height
90 mm
- Length
54.5 mm
- Type
NT-35-24
Documents & Downloads
Datasheet
Datasheet 2378661 Spelsberg 72212001 Rail mounted PSU (DIN) 0.63 A 15.2 W No. of outputs:1 x Content 1 pc(s)
Datasheet 2378661 Spelsberg 72212001 Rail mounted PSU (DIN) 0.63 A 15.2 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2378661 Spelsberg 72212001 Rail mounted PSU (DIN) 0.63 A 15.2 W No. of outputs:1 x Content 1 pc(s)
Description
Power supply for mounting on standard rail NS35. Input voltage 85V to 264 V AC, output voltage 21.6 V -29 V DC. Capacity max. 15.2 W.
This text is machine translated.
This text is machine translated.
Hints
Safety-relevant component - installation only by skilled workers
