Sunon CF2082HVL-1000U-999 Axial fan 230 V AC 67.94 m³/h (L x W x H) 25 x 80 x 80 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
230 V AC
Power
3.2 W
Type of bearing
Vapo (magnetic)
Air flow rate
67.94 m³/h
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 28.56
3
4% = € 1.24
€ 27.32
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 28.56 / piece)
€ 28.56
plus VAT.
Technical specifications
- Connection type: Wire, AWG24, UL3266, 30cm, stripped, tin-plated
- Product type
Axial fan
- Type
CF2082HVL-1000U-999
- Nominal voltage
230 V AC
- Min. operating voltage
200 V AC
- Max. operating voltage
240 V AC
- Operating voltage
200 - 240 V AC
- Max. current consumption
0.17 A
3.2 W
- Type of bearing
Vapo (magnetic)
- Rotational speed
3100 U/min
- Noise emission (max.)
32 dB
- Air flow rate
67.94 m³/h
- Connection
Braid
- Pressure (max.)
34.86 Pa
- Factory colour
Black
- Material
Thermoplastic
- Weight
131.6 g
- Min. temperature
-20 °C
- Max. temperature
70 °C
- Length
25 mm
- Width
80 mm
- Height
80 mm
- Dim
(L x W x H) 25 x 80 x 80 mm
Documents & Downloads
Datasheet
Datasheet 2996463 Sunon CF2082HVL-1000U-999 Axial fan 230 V AC 67.94 m³/h (L x W x H) 25 x 80 x 80 mm
User & Safety Instructions
User & Safety Instructions 2996463 Sunon CF2082HVL-1000U-999 Axial fan 230 V AC 67.94 m³/h (L x W x H) 25 x 80 x 80 mm
