Sunon DP201A-2123HBT.S.GN Axial fan 230 V AC 144.38 m³/h (L x W x H) 38 x 120 x 120 mm

A black fan by SUNON, model number SP100A, suitable for 115V and 50/60Hz, manufactured in China.
Product type
Axial fan
Nominal voltage
230 V AC
Power
10.8 W
Type of bearing
Ball bearing
Air flow rate
144.38 m³/h
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
19 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 19.99 / piece)
€ 19.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

  • Connection type: Integrated flat plug (2.8x0.5mm)
Product type

Axial fan

Type

DP201A-2123HBT.S.GN

Nominal voltage

230 V AC

Min. operating voltage

185 V AC

Max. operating voltage

245 V AC

Operating voltage

185 - 245 V AC

Max. current consumption

0.069 A

10.8 W

Type of bearing

Ball bearing

Rotational speed

2550 U/min

Noise emission (max.)

44 dB

Air flow rate

144.38 m³/h

Connection

Type C CEE 7/16 plug 2.8 mm

Pressure (max.)

62.25 Pa

Factory colour

Black

Material

Thermoplastic

Weight

480 g

Min. temperature

-10 °C

Max. temperature

70 °C

Length

38 mm

Width

120 mm

Height

120 mm

Dim

(L x W x H) 38 x 120 x 120 mm

Documents & Downloads

Datasheet

Datasheet 2992650 Sunon DP201A-2123HBT.S.GN Axial fan 230 V AC 144.38 m³/h (L x W x H) 38 x 120 x 120 mm

User & Safety Instructions

User & Safety Instructions 2992650 Sunon DP201A-2123HBT.S.GN Axial fan 230 V AC 144.38 m³/h (L x W x H) 38 x 120 x 120 mm
