Sunon MF50152VX-1000U-A99 Axial fan 24 V DC 31.59 m³/h (L x W x H) 15 x 50 x 50 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
24 V DC
Power
1.32 W
Type of bearing
Vapo (magnetic)
Air flow rate
31.59 m³/h
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€ 4.61
plus VAT.
Technical specifications
- Connection type: UL1007 AWG26 wires, stripped, tin-plated
- Product type
Axial fan
- Type
MF50152VX-1000U-A99
- Nominal voltage
24 V DC
- Min. operating voltage
8 V DC
- Max. operating voltage
27.6 V DC
- Operating voltage
8 - 27.6 V DC
- Max. current consumption
0.055 A
1.32 W
- Type of bearing
Vapo (magnetic)
- Rotational speed
7200 U/min
- Noise emission (max.)
38.1 dB
- Air flow rate
31.59 m³/h
- Connection
Braid
- Pressure (max.)
77.19 Pa
- Factory colour
Black
- Material
Thermoplastic
70000 h
- Weight
44 g
- Min. temperature
-10 °C
- Max. temperature
70 °C
- Length
15 mm
- Width
50 mm
- Height
50 mm
- Dim
(L x W x H) 15 x 50 x 50 mm
Documents & Downloads
Datasheet
Datasheet 2992707 Sunon MF50152VX-1000U-A99 Axial fan 24 V DC 31.59 m³/h (L x W x H) 15 x 50 x 50 mm
User & Safety Instructions
User & Safety Instructions 2992707 Sunon MF50152VX-1000U-A99 Axial fan 24 V DC 31.59 m³/h (L x W x H) 15 x 50 x 50 mm
