Buy T.I.P. - Technische Industrie Produkte 30140 Maxima 400 CX Effluent sump pump 24000 l/h 9 m

Silver-coloured submersible pump with a red switch and black base. Label reads: 'T.I.P. Maxima 400 CX'.

Part of a metallic device, combined with a black hexagon on the right side with the inscription 'CAST'.

A diagram shows a float switch with labels 'ON' and 'OFF'. It protects against dry running.

'High-Performance Pump Maxima 400 CX by T.I.P. with 250 Watts. Maximum Delivery Capacity: 2450 l/h, Maximum Delivery Height: 9 m at 0.9 bar.'

1/5

Datasheet (PDF)

Fast track dispatch on Tue, 22 Sep

8 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 147.05 / piece)

€ 147.05

plus VAT.

Only 8 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Waste water submersible pump Maxima 400CX

Maximum flow 24000 l/h
Maximum pump lift: 9 m
Max. solids size 35 mm

Technical specifications

Minimum suction level: 40 mm

Product type: Effluent sump pump

Max. delivery head: 9 m

Max. feed rate: 24000 l/h

Max. discharge pressure: 0.9 bar

Operating voltage: 230 V

Power consumption (P1): 950 W

Pressure connection: 44.9 mm (1 1/2") IT

Max. size of solids: 35 mm

Immersion depth: 5 m

Max. cable length: 10 m

Float switch: Yes

Overload protection: Yes

Weight: 13.40 kg

Documents & Downloads

Datasheet

Datasheet 1176273 T.I.P. - Technische Industrie Produkte 30140 Maxima 400 CX Effluent sump pump 24000 l/h 9 m

User & Safety Instructions

User & Safety Instructions 1176273 T.I.P. - Technische Industrie Produkte 30140 Maxima 400 CX Effluent sump pump 24000 l/h 9 m

Warranty Terms

Warranty Terms 1176273 T.I.P. - Technische Industrie Produkte 30140 Maxima 400 CX Effluent sump pump 24000 l/h 9 m

Description

As a specially designed baupumpe is characterised the MAXIMA 400CX by extraordinary robustness as well as through an extremely high flow rate. Since when used in construction and waste water pits the highest demands on pumps are hydraulic housing and the almost indestructible impeller made of cast.

This text is machine translated.

Scope of delivery

Waste water submersible pump
Connection sheets: Hose 38 mm/thread IG 45,48 mm (1 1/2")-connection sheets: Hose 32 mm/thread IG 39,59 mm (1 1/4")-Reducer: IG 45,48 mm (1 1/2") AG 41.91 mm (1 1/4") -Double nipple: AG 47.80 mm (1 1/2") AG 47.80 mm (1 1/2")
User manual.
