TDK-Lambda PXC-M03-48WS24 DC/DC converter (print) 24 V 125 mA Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 53.77 / piece)
€ 53.77
plus VAT.
14-day return policy included
Highlights & Details
DC DC Converters
- Medical approval according to 60601-1 (3rd Edition)2MOPP, 5kVac insulation for 1 minuteLow patient leakage current 0.25 < μACompact medical 4:1 DC-DC converter (24V/48Vnom.)
Technical specifications
- Product type
DC/DC converter (print)
- Type
PXC-M03-48WS24
- Min. input voltage
18 V
- Input voltage (max.)
75 V
- Output voltages
24 V
- Max. output current
125 mA
- Output current (max.) - rounded
125 mA
- Efficiency (max.)
86.5 %
- Insulation voltage
5000 V AC
- Enclosure
DIP 24
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+94 °C
- Dim
(L x W x H) 31.8 x 20.3 x 10.2 mm
- Height
10.2 mm
- Length
31.8 mm
- Width
20.3 mm
- RoHS-compliant
Yes
- Weight
14 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2255890 TDK-Lambda PXC-M03-48WS24 DC/DC converter (print) 24 V 125 mA Content 1 pc(s)
Datasheet 2255890 TDK-Lambda PXC-M03-48WS24 DC/DC converter (print) 24 V 125 mA Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2255890 TDK-Lambda PXC-M03-48WS24 DC/DC converter (print) 24 V 125 mA Content 1 pc(s)
Warranty Terms
Warranty Terms 2255890 TDK-Lambda PXC-M03-48WS24 DC/DC converter (print) 24 V 125 mA Content 1 pc(s)
Description
The PXC-M DC-DC converter range has a wide 4:1 input voltage range, medical approval, 5 kV AC input/output isolation voltage, 3/6/10W output power and a standard DIP 24 housing. The modules are suitable for a wide range of applications, especially in medical applications – including applications with patient contact thanks to 2 x MOPP – and battery-operated applications.The compact DC-DC-modules convert 9-36 V DC or 18-75 V DC input voltage in 3.3, 5, 12, 15, 24, ±5, ±12 or ±15 V DC. Since their inputs each cover two typical DC supply ratings (12 and 24 V and 48 V respectively), they facilitate storage by improving availability and reducing costs.
